中空玻璃生產線的調試方法
Debugging method of insulating glass production line
1 將中空玻璃生產線輕置于安裝位,正確擺放生產線各段的位置次序.
1 place the insulating glass production line gently at the installation position, and correctly place the position order of each section of the production line
2 機身調平.調整機器底座上調平螺栓高度,使傳送輥、支撐尼龍輪支撐面等高,斜架上的背靠輪共面,各段相對平行,然后鎖緊螺母.
2 fuselage leveling Adjust the height of the leveling bolt on the machine base so that the supporting surfaces of the transfer roller and the supporting nylon wheel are equal in height, the back-up wheels on the inclined frame are coplanar, and each section is relatively parallel, and then lock the nut
3 將各段間需聯接的部位聯接緊固,聯接好由入料段到清洗干燥段的傳動鏈條.正確擺放風機及水箱,并按水路、風路系統圖接好風管、水管.
3 connect and fasten the parts to be connected between the sections, and connect the transmission chain from the feeding section to the cleaning and drying section Place the fan and water tank correctly, and connect the air pipe and water pipe according to the water and air system diagram

4 一體檢查機器所有緊固件連接處是否因運輸震動而松動,并逐件緊固(非常是各接線端子連接處是否松動).
4 check whether all fastener connections of the machine are loose due to transportation vibration, and tighten them one by one (especially whether the connection of each wiring terminal is loose)
5 接地線用截面積不小于4平方毫米的軟銅心黃綠絕緣線,接地電阻不大于4 歐姆.
5 the soft copper core yellow green insulated wire with a cross-sectional area of not less than 4mm2 shall be used for the grounding wire, and the grounding resistance shall not be greater than 4 ohms
6 接通氣源,檢查管路是否通暢,有無破損.氣源壓力要求0.6~0.8Mpa.
6 connect the air source and check whether the pipeline is smooth and damaged The air supply pressure shall be 0.6~0.8mpa
7 接通電源,試驗各電機的旋轉方向是否正確,各段傳動鏈輪是否靈活、平穩.
7. Turn on the power supply and test whether the rotation direction of each motor is correct and whether the drive sprocket of each section is flexible and stable
8 整機清潔,整理工作區間.
8. Clean the whole machine and arrange the working area
