1、丁基膠涂布機選用人機界面顯示屏便于操作，系統以PLC為操控中心，由光電傳感PLC機、中文操控終端、PLC自動轉化。按鈕開關等電器元件組成，功能強壯、作業牢靠、操作簡略自動化程度較高。
1. The butyl rubber coating machine adopts human-machine interface display screen for easy operation. The system takes PLC as the control center and is automatically converted by photoelectric sensor PLC, Chinese control terminal and PLC. It is composed of button switch and other electrical components, with strong function, reliable operation, simple operation and high degree of automation.
2、丁基膠涂布機選用目前國內較大缸徑膠缸，裝膠容量大，較大出眾保證連續出產時間，行進作業功率。選用較氣動增壓系統，充沛保證膠頭出膠壓力衡定，避免了打膠粗細不勻，斷膠現象。選用4段變頻調速，較大出眾照顧操作工人熟練程度，行進作業功率。
2. The butyl rubber coating machine adopts the rubber cylinder with large cylinder diameter at present in China, which has large rubber loading capacity and large limit to ensure continuous production time and traveling operation power. The more advanced pneumatic pressurization system is used to fully ensure the constant pressure of the rubber head, and avoid the uneven thickness and broken rubber. The 4-stage frequency conversion speed regulation is selected to take into account the proficiency of the operators and the traveling power.
3、丁基膠涂布機為中空玻璃出產的首要必備設備，為半自動膠條涂布機，即人工持鋁間隔框進行操作，將鋁間隔框放在傳送帶上，人工持鋁間隔框隨傳送帶作業，當鋁間隔框經過傳感器時，傳送壓輪及打膠閥將按設定程序自動作業，即氣缸動作，壓輪壓下，壓送鋁間隔框進行;待鋁間隔框抵達打膠頭時初步打膠，將膠均勻地涂在鋁間隔框上，當間隔框另一側快要抵達壓輪時，壓輪抬起，離開打膠頭時，膠閥自動間斷打膠。
3. The butyl rubber coating machine is the first necessary equipment for the production of insulating glass. It is a semi-automatic rubber strip coating machine, that is, manually holding the aluminum spacer frame to operate, placing the aluminum spacer frame on the conveyor belt, and manually holding the aluminum spacer frame to operate with the conveyor belt. When the aluminum spacer frame passes through the sensor, the transmission pressure wheel and the gluing valve will operate automatically according to the set procedure, that is, the cylinder will act, the pressure wheel will press down, and the aluminum spacer frame will be pressed; When the aluminum spacing frame reaches the gluing head, apply the glue evenly on the aluminum spacing frame. When the other side of the spacing frame is about to reach the pressing wheel, the pressing wheel will lift, and when it leaves the gluing head, the glue valve will automatically stop gluing.

4、主要功能有：
4. Main functions include:
(1)膠頭、膠缸自動加熱功能
(1) Automatic heating function of rubber head and rubber cylinder
(2)任意設置自動加熱時間
(2) Set the automatic heating time arbitrarily
(3)無膠報警提示
(3) No glue alarm prompt
(4)在手動狀態下可打圓弧
(4) Arc can be made in manual mode
(5)自動待機功能：減少工人值守時間，行進作業功率。
(5) Automatic standby function: reduce workers' duty time and travel operation power.
5、丁基膠涂布機選用不銹鋼作業臺面，充沛保證設備外觀及收拾便當。
5. The butyl adhesive coating machine uses stainless steel working table to fully ensure the equipment appearance and easy cleaning.
