丁基膠涂布機是槽鋁式中空玻璃生產加工工藝中不可缺少的專用設備，其作用是將熱熔的丁基膠均勻地涂布在鋁間隔框上。丁基膠作為中空玻璃的第一道密封材料，其涂布質量直接影響中空玻璃的整體密封性能和使用壽命。因此，丁基膠涂布機在中空玻璃生產線上占據著不可替代的重要地位。

The butyl rubber coating machine is an indispensable specialized equipment in the production and processing technology of slot aluminum insulated glass. Its function is to evenly coat the hot-melt butyl rubber on the aluminum spacer frame. As the first sealing material for insulating glass, the coating quality of butyl rubber directly affects the overall sealing performance and service life of the insulating glass. Therefore, the butyl rubber coating machine plays an irreplaceable and important role in the production line of insulating glass.

丁基膠涂布機的工作原理基于熱熔膠的加熱熔融與定量涂布。設備將固態的丁基膠在膠缸中加熱至熔融狀態，然后通過擠壓系統將熔融的丁基膠從膠嘴中擠出，均勻涂布在鋁間隔框的兩側。在操作方式上，傳統的丁基膠涂布機為半自動機型，即人工扶持鋁間隔框進行逐邊操作。操作人員將鋁間隔框放在傳送帶上，人工扶持間隔框隨傳送帶行進。當間隔框通過傳感器時，傳送壓輪及打膠閥按設定程序自動動作——擺動氣缸動作、壓輪壓下，壓送鋁間隔框行進。待間隔框到達打膠頭時開始打膠，將丁基膠均勻地涂在鋁間隔框上。當間隔框另一側快要到達壓輪時，壓輪抬起，離開打膠頭時膠閥自動關閉，停止打膠。

The working principle of the butyl rubber coating machine is based on the heating and melting of hot melt adhesive and quantitative coating. The device heats the solid butyl rubber in the rubber cylinder to a molten state, and then extrudes the molten butyl rubber from the rubber nozzle through an extrusion system, evenly coating it on both sides of the aluminum spacer frame. In terms of operation, the traditional butyl rubber coating machine is a semi-automatic model, which manually supports the aluminum spacer frame for edge by edge operation. The operator places the aluminum spacer frame on the conveyor belt and manually supports the spacer frame to move along with the conveyor belt. When the interval frame passes through the sensor, the conveying pressure wheel and glue valve automatically move according to the set program - the swing cylinder moves, the pressure wheel presses down, and the aluminum interval frame moves forward. Start gluing when the spacer box reaches the gluing head, and evenly apply butyl glue on the aluminum spacer box. When the other side of the interval frame is about to reach the pressure roller, the pressure roller lifts up and leaves the glue head. The glue valve automatically closes and stops gluing.

在核心技術方面，丁基膠涂布機采用氣液增壓泵提供打膠壓力，具有壓力平穩、保壓可靠的優點。膠缸與膠嘴采用雙加熱系統，溫控表可準確控制溫度，打膠溫度通常在100℃-150℃之間。膠缸直徑通常為195mm左右，容量大，可避免頻繁加膠。膠頭部分采用先進的出膠結構，可根據鋁條的寬度不卸壓自由調節兩膠頭的間距。膠頭可調范圍通常為4-20mm。

In terms of core technology, the butyl rubber coating machine adopts a gas-liquid booster pump to provide adhesive pressure, which has the advantages of stable pressure and reliable pressure maintenance. The glue cylinder and nozzle adopt a dual heating system, and the temperature control meter can accurately control the temperature. The glue dispensing temperature is usually between 100 ℃ and 150 ℃. The diameter of the glue cylinder is usually around 195mm, with a large capacity, which can avoid frequent glue addition. The adhesive head adopts an advanced dispensing structure, which can freely adjust the spacing between the two adhesive heads according to the width of the aluminum strip without unloading pressure. The adjustable range of the adhesive head is usually 4-20mm.

在傳動與控制方面，皮帶傳送采用變頻器控制，具有多個段速，可根據操作工人的熟練程度自行調節。傳送皮帶選用優良的片基帶，經久耐用，整帶裝有漲緊裝置，調節方便、維修簡單。整機采用光電和PLC控制系統，新穎的雙壓輪定位，傳送、涂膠均可通過人機界面調整。操作界面采用觸摸屏人機界面，操作方便、性能可靠。設備具有定時開關機功能，工作氣壓、涂膠量、鋁條寬度等參數均可根據實際需要進行調節。

In terms of transmission and control, the belt conveyor adopts frequency converter control, with multiple section speeds that can be adjusted according to the proficiency of the operator. The conveyor belt is made of high-quality base tape, which is durable and long-lasting. The entire belt is equipped with a tensioning device, making it easy to adjust and maintain. The whole machine adopts a photoelectric and PLC control system, with a novel dual pressure wheel positioning. The conveying and gluing can be adjusted through the human-machine interface. The operation interface adopts a touch screen human-machine interface, which is easy to operate and reliable in performance. The equipment has a timed power on/off function, and parameters such as working pressure, glue application amount, and aluminum strip width can be adjusted according to actual needs.

在技術參數方面，典型丁基膠涂布機的輸入電源為380V、50Hz，輸入功率約2.5-3.5KW。工作氣壓為0.5-0.8Mpa。擠膠壓力為12-20Mpa。輸出速度為0-22m/min。打膠速度約為22米/分鐘。外形尺寸約為3000×650×1100mm，重量約700-850kg。

In terms of technical parameters, the input power of a typical butyl rubber coating machine is 380V, 50Hz, with an input power of about 2.5-3.5KW. The working pressure is 0.5-0.8Mpa. The extrusion pressure is 12-20Mpa. The output speed is 0-22m/min. The gluing speed is about 22 meters per minute. The external dimensions are about 3000 × 650 × 1100mm, and the weight is about 700-850kg.

丁基膠涂布機在設計中充分考慮了用戶的實際操作需求。膠頭采用可調定位機構，充分保證涂膠膠頭與隔框兩側間距均勻。設備具備數字化控制出膠和停膠時間功能，無膠時自動顯示。設備由PC機控制，可自動準確完成涂膠動作。采用雙密封圈設計，密封性能更加可靠。丁基膠涂布機是雙道密封中空玻璃生產中必不可少的設備。隨著中空玻璃生產向自動化、智能化方向不斷發展，丁基膠涂布機也在從半自動向全自動方向演進，新型的自動丁基膠涂布機通過螺桿傳動組件實現鋁隔條框輸送過程中的自動涂膠，進一步提升了生產效率和涂膠質量的穩定性。

The design of the butyl rubber coating machine fully considers the actual operational needs of users. The adhesive head adopts an adjustable positioning mechanism to ensure even spacing between the adhesive head and the two sides of the partition frame. The equipment has digital control of dispensing and stopping time functions, and automatically displays when there is no glue. The device is controlled by a PC and can automatically and accurately complete the gluing action. Adopting a dual sealing ring design, the sealing performance is more reliable. The butyl rubber coating machine is an essential equipment in the production of double sealed insulating glass. With the continuous development of automation and intelligence in the production of insulating glass, the butyl rubber coating machine is also evolving from semi-automatic to fully automatic. The new automatic butyl rubber coating machine achieves automatic coating during the conveying process of aluminum spacer frames through screw transmission components, further improving production efficiency and the stability of coating quality.
